| Ukuran/Berat |
| Dimensi |
Lebar |
1,472mm (58") |
1,320mm (51.9") |
| Tinggi |
173mm (6-3/4") |
173mm (6-3/4") |
| Kedalaman |
385mm (15-1/4") |
385mm (15-1/4") |
| Berat |
Berat |
22.4kg (49.6 lbs.) |
20.4kg (44.2 lbs.) |
| Control Interface |
| Keyboard |
Jumlah Tuts |
88 |
76 |
| Tipe |
Balanced Hammer Effect Keyboard |
Balanced Hammer Effect Keyboard |
| Initial Touch |
Yes |
Yes |
| Aftertouch |
Yes |
Yes |
| Display |
Tipe |
graphic backlit LCD |
graphic backlit LCD |
| Ukuran |
160×64 dot |
160×64 dot |
| Pengaturan Interface |
| Pengaturan Lain |
Lengkungan Pitch |
Yes |
Yes |
| Modulasi |
Yes |
Yes |
| Control Slider |
Assignable Control sliders x 4 |
Assignable Control sliders x 4 |
| Pengatur Knob |
Assignable Control knobs x 4 |
Assignable Control knobs x 4 |
| Lain-lain |
Assignable Fucntion button x 2, Data Dial, Input Gain |
Data Dial |
| Tampilan |
Lampu Belakang |
Yes |
Yes |
| Penyelaras |
Yes |
Yes |
| Suara |
| Tingkatan Nada |
Teknologi Generate Nada |
AWM2 with Expanded Articulation |
AWM2 with Expanded Articulation |
| Kapasitas Multi Timbral |
16 Internal Parts + Mic Input Part |
16 Internal Parts + Mic Input Part |
| Ware ROM Capacity |
456 MB (when converted to 16-bit linear format), 2,772 waveforms |
456 MB (when converted to 16-bit linear format), 2,772 waveforms |
| Preset |
Jumlah Voice |
Preset: 1,024 normal voices + 64 drum kits, GM: 128 normal voices + 1 drum kits, User: 128 x 4 (Bank 1 - 3: selected and copied from Preset bank) Normal Voice + 32 drum kits |
Preset: 1,024 normal voices + 64 drum kits, GM: 128 normal voices + 1 drum kits, User: 128 x 4 (Bank 1 - 3: selected and copied from Preset bank), Normal Voice + 32 drum kits |
| Voice |
| Polifoni |
Jumlah Polifoni (Max.) |
128 |
128 |
| Efek |
| Tipe |
Reverb |
9 types |
9 types |
| Chorus |
22 types |
22 types |
| Insertion |
54 types x 8 blocks |
54 types x 8 blocks |
| Efek Master |
9 types |
9 types |
| EQ Utama |
5 bands |
5 bands |
| Bagian EQ |
3 bands, stereo |
3 bands, stereo |
| Lagu |
| Rekaman |
Number of Arpegio |
Preset x 6,779 typesUser x 256 types (when loading the User Arpeggio data of MOTIF XS) |
Preset x 6,779 typesUser x 256 types (when loading the User Arpeggio data of MOTIF XS) |
| Format Data Kompatibel |
Playback |
SMF Format 0/1 (playback only) |
SMF Format 0/1 (playback only) |
| Penyimpanan dan Koneksi |
| Penyimpanan |
Memori Internal |
192MB |
192MB |
| Koneksi |
Headphone |
PHONES (standard stereo phone jack) |
PHONES (standard stereo phone jack) |
| Mikrofon |
MIC INPUT (combo jack) |
MIC INPUT (combo jack) |
| MIDI |
MIDI IN/OUT/THRU |
MIDI IN/OUT/THRU |
| USB TO DEVICE |
USB (TO DEVICE) |
USB (TO DEVICE) |
| USB TO HOST |
USB (TO HOST) |
USB (TO HOST) |
| Penyimpanan dan Sambungan |
| Sambungan |
AC IN |
Yes |
Yes |
| Foot Control |
FOOT CONTROLLER1, 2 |
FOOT CONTROLLER1, 2 |
| Penggantian Kaki |
FOOT SWITCH x 2 (SUSTAIN, ASSIGNABLE) |
FOOT SWITCH x 2 (SUSTAIN, ASSIGNABLE) |
| Assignable OUT |
ASSIGNABLE OUTPUT L, R (standard phone jack) |
ASSIGNABLE OUTPUT L, R (standard phone jack) |
| LINE OUT |
OUTPUT L/MONO, R (standard phone jack) |
OUTPUT L/MONO, R (standard phone jack) |
| Suplai Daya |
| Konsumsi Daya |
25W |
25W |
| Berkas Perangkat Lunak |
| CD-ROM |
Cubase AI Disc x 1 |
Cubase AI Disc x 1 |
| Aksesori |
| Aksesori yang Termasuk |
Lain-lain |
AC Power cord, Owner's Manual, Owner's Manual CD-ROM (containing Reference Manual and Data List) |
AC Power cord, Owner's Manual, Owner's Manual CD-ROM (containing Reference Manual and Data List) |
