| Ukuran/Berat |
| Dimensi |
Lebar |
1.461 mm [57-1/2"]
|
| Tinggi |
927 mm [36-1/2"]
|
| Kedalaman |
459 mm [18-1/16"]
|
| Berat |
Berat |
56,0 kg (123 lb., 7 oz.)
|
| Carton Box |
Lebar |
1.571 mm [61-27/32"]
|
| Tinggi |
639 mm [25-5/32"]
|
| Kedalaman |
569 mm [22-13/32"]
|
| Control Interface |
| Keyboard |
Jumlah Tuts |
88 |
| Tipe |
Keyboard GH3 dengan bagian atas tuts dari eboni dan gading sintetis |
| Respon Sentuhan |
Hard2/Hard1/Medium/Soft1/Soft2/Fixed |
| Pedal |
Jumlah Pedal |
3: Damper (dengan efek setengah pedal), Sostenuto, Soft |
| Fungsi |
Sustain (Sakelar), Sustain Continuously, Sostenuto, Soft, Expression, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause
|
| Display |
Tipe |
Full Dots LCD |
| Ukuran |
128 x 64 dot
|
| Bahasa |
Bahasa Inggris |
| Panel |
Bahasa |
Bahasa Inggris |
| Kabinet |
| Key Cover |
Key Cover Style |
Sliding |
| Music Rest |
Ya |
| Klip Musik |
- |
| Voice |
| Tone Generation |
Suara Piano |
Yamaha CFX |
| Key-off Sample |
Ya |
| Smooth Release |
Ya |
| Virtual Resonance Modeling (VRM) |
Ya |
| Virtual Resonance Modeling Lite (VRM Lite) |
- |
| Polifoni |
Jumlah Polifoni (Max.) |
256 |
| Preset |
Jumlah Voice |
24 |
| Efek |
| Tipe |
Reverb |
6 |
| Chorus |
3 |
| Briliance |
7 |
| Efek Master |
11 |
| Intelligent Acoustic Control (IAC) |
Ya |
| Stereophonic Optimizer |
Ya |
| Fungsi |
Dual/Layers |
Ya |
| Split |
Ya |
| Duo |
Ya |
| Lagu |
| Preset |
Jumlah Lagu Preset |
14 lagu demo voice + 50 klasik |
| Perekaman |
Jumlah Lagu |
250 |
| Jumlah Track |
16 |
| Kapasitas Data |
Kurang lebih 500 KB/Lagu |
| Format Data Kompatibel |
Playback |
SMF (Format 0, Format 1) |
| Perekaman |
SMF (Format 0) |
| Fungsi |
| Piano Room |
Ya |
| Pengaturan Keseluruhan |
Metronome |
Ya |
| Rentang Tempo |
5 ‒ 500 |
| Transpose |
-12 ‒ 0 ‒ +12 |
| Tuning |
414,8 - 440,0 - 466,8 Hz (dengan pertambahan setiap sekitar 0,2 Hz) |
| Tipe Tangga Nada |
7 |
| Rhythm |
20 |
| Penyimpanan dan Koneksi |
| Penyimpanan |
Memori Internal |
Total ukuran maksimal kurang lebih 1,5 MB |
| Drive Eksternal |
USB flash drive |
| Konektivitas |
Headphone |
Standard stereo phone jack (x 2) |
| MIDI |
[IN] [OUT] [THRU] |
| AUX IN |
Mini Stereo |
| AUX OUT |
[L/L+R] [R] |
| USB TO DEVICE |
Ya |
| USB TO HOST |
Ya |
| DC IN |
16 V |
| Amplifier dan Speaker |
| Amplifier |
30 W x 2 |
| Speaker |
16 cm x 2 |
| Suplai Daya |
| Konsumsi Daya |
20 W (saat menggunakan adaptor AC PA-150B) |
| Auto Power Off |
Ya |
| Suplai Daya |
Adaptor |
PA-300C |
| Aksesori |
| Aksesori |
Panduan Pemilik, Buku Musik 50 Karya Musik Klasik, Registrasi Produk Anggota Online, Garansi*, Bangku*, Kabel daya*/Adaptor AC* PA-300C *bervariasi berdasarkan wilayah
|
